Component Kits





This handy capacitor kit contains all the common values between 100nF to 1000µF, which makes it ideal for hobbyists and technicians alike. The 105°C rating ensures that the capacitors retein their reliability even in high temperature environments. It comes in a handy partitioned box.



This kit contains the following values:



100nF @ 50V

220nF @ 50V

470nF @ 50V

1µF @ 50V

2.2µF @ 50V

3.3µF @ 50V

4.7µF @ 50V

10µF @ 25V

10µF @ 50V

22µF @ 16V

22µF @ 25V

33µF @ 16V

47µF @ 10V

47µF @ 25V

47µF @ 50V

100µF @ 16V

100µF @ 25V

220µF @ 10V

220µF @ 25V

330µF @ 50V

470µF @ 10V

470µF @ 16V

680µF @ 16V

1000µF @ 16V





Supplied with the kit:

The Arduino IDE Software can be downloaded from the Arduino website here

https://www.arduino.cc/en/Main/Software



You can download a copy of the starter projects CD here



Installing the Arduino IDE

1. Go to arduino.cc/en/software and download the appropriate version for your system.
2. Run the installation file (usually called arduino-1.xx.xx-windows.exe).
3. Follow the on-screen instructions to complete the installation process.


Connecting the Arduino to a computer

1. Connect the Arduino to your computer using the USB cable provided.
2. Open the Arduino IDE and click on “Tools”. When prompted by windows firewall click allow.
3. Move the cursor over “Board” and select your Arduino board from the list (e.g. “Arduino Uno”).
4. Click on “Tools” again and move the cursor over “Port”. Now, select the USB port where the Arduino is plugged in. If you have multiple devices under “Ports” and you are unsure which one is the Arduino, try selecting one of the ports and then click on “Tools” and select “Get board info”. If the Arduino port is selected, a small window displaying the board information will appear, otherwise keep trying different ports until the window appears.
5. To check if the Arduino is connected correctly, click on the “Upload” button at the top of the screen (button with arrow pointing to the right) and wait for the empty sketch to upload. If no errors come up, you’re all set up and ready to go!


Installing Arduino Libraries

Method 1

1. Open the Arduino IDE and click on “Tools” at the top of the screen.
2. Click on “Manage Libraries”.
3. Type in the name of the library you wish to install (e.g. “CCS811”) and press enter.
4. The Library Manager will now display a number of relevant libraries. Hover the cursor over the required library and click “Install”. When the installation has finished, close the Library Manager window.

Method 2

1. Download the library you wish to install.
2. Extract the folder from the zip file and paste it in the following location:

         Windows XP and above: C:\Users\%username%\Documents\Arduino\Libraries

         Mac: /Users//Documents/Arduino/libraries/

         Linux: /usr/share/arduino/libraries/ (you must delete the dashes in the folder name, if there are any)

3. Restart the Arduino IDE.



Supplied with the kit:

1 x ESP32 development board
1× 0.96-inch OLED
1 × 830 tethered chest board
1 × Obstacle avoidance module
1 × photoresistor module
1× DHT11 temperature and humidity module
1X HC-SR501 PIR Motion Sensor
1 × Potentiometer (10K)
1 x Micro USB Cable
30 x Resistors (220R/1K/10K)
1 x Passive Buzzer
1 × Active Buzzer
1 × 5V dual-channel relay module
6 × Pushbutton Switch
10 × F-M Dupont Cable
10X F-F DuPont Cable
10X M-M DuPont cable
5 × LED red
5X LED Yellow
5X LED Green
1 x RGB LED

The Arduino IDE Software can be downloaded from the Arduino website here (Yes, it will work with ESP32 as well)

https://www.arduino.cc/en/Main/Software





Installing the Arduino IDE

1. Go to arduino.cc/en/software and download the appropriate version for your system.
2. Run the installation file (usually called arduino-1.xx.xx-windows.exe).
3. Follow the on-screen instructions to complete the installation process.


Connecting the Arduino to a computer

1. Connect the ESP32 to your computer using the USB cable provided.
2. Open the Arduino IDE and click on “Tools”. When prompted by windows firewall click allow.
3. Move the cursor over “Board” and select your ESP32 board from the list (e.g. “ESP-32S”). If your board is not in the list you ll have to add it in the "Boards Manager" (See Bellow)
4. Click on “Tools” again and move the cursor over “Port”. Now, select the USB port where the ESP32 is plugged in. If you have multiple devices under “Ports” and you are unsure which one is the ESP32, try selecting one of the ports and then click on “Tools” and select “Get board info”. If the ESP32 port is selected, a small window displaying the board information will appear, otherwise keep trying different ports until the window appears.
5. To check if the  ESP32 is connected correctly, click on the “Upload” button at the top of the screen (button with arrow pointing to the right) and wait for the empty sketch to upload. If no errors come up, you’re all set up and ready to go!


Installing Arduino Libraries

Method 1

1. Open the Arduino IDE and click on “Tools” at the top of the screen.
2. Click on “Manage Libraries”.
3. Type in the name of the library you wish to install (e.g. “CCS811”) and press enter.
4. The Library Manager will now display a number of relevant libraries. Hover the cursor over the required library and click “Install”. When the installation has finished, close the Library Manager window.

Method 2

1. Download the library you wish to install.
2. Extract the folder from the zip file and paste it in the following location:

         Windows XP and above: C:\Users\%username%\Documents\Arduino\Libraries

         Mac: /Users//Documents/Arduino/libraries/

         Linux: /usr/share/arduino/libraries/ (you must delete the dashes in the folder name, if there are any)

3. Restart the Arduino IDE.

Adding boards to Boards Manager

1. Open the Arduino IDE
2. Click on “Boards Manager” button on the very left side of the screen.
3. Type in the name of the board you wish to add (e.g. “ESP32”) and press enter. In this case we need "esp32" by Expressif Systems
4. The Boards Manager will now display a number of relevant libraries. Hover the cursor over the required library and click “Install”.





3mm White 40pcs - 2.8V @ 5mA

3mm Blue 40pcs - 2.7V @ 5mA

3mm Green 40pcs - 1.9V @ 5mA

3mm Red 40pcs - 1.9V @ 5mA

3mm Yellow 40pcs - 1.9V @ 5mA

5mm White 20pcs - 2.8V @ 5mA

5mm Blue 20pcs - 2.7V @ 5mA

5mm Green 20pcs - 2V @ 5mA

5mm Red 20pcs - 1.9V @ 5mA

5mm Yellow 20pcs - 3.3V @ 5mA





This capacitor kit comes with 24 different capacitor values. Suitable for projects, servicing & hobby.



20 pieces per value of the following:



10pF, 22pF, 30pF, 47pF, 100pF, 220pF, 330pF, 470pF, 1nF, 2.2nF, 3.3nF, 4.7nF, 6.8nF, 10nF, 22nF, 47nF, 68nF, 100nF, 220nF, 470nF, 1µF, 2.2µF, 4.7µF, 10µF
