Motion

Motion
Page of 2
Quick View
Dual axis joystick module for Arduino KY-023

Dual axis joystick module for Arduino KY-023

KY023

Dual axis joystick module for Arduino and other microcontroller projects


This module uses 2 10k potentiometers, one for the X axis and one for the Y axis.
It also has a switch that is activated when the joystick is pressed down.

Voltage : 3.5 to 5VDC
Size 34x27mm

£2.75

(inc VAT £3.30)
Quantity
Quick View
Geared Motor with Wheel

Geared Motor with Wheel

GM65

Geared Motor with Wheel and Tyre



This is a 3-9 VDC Motor with a buiIt in gearbox to give speeds of 90-300 RPM (under no load conditions). It is supplied with a 65mm wheel and tyre making it ideal for robot type car projects and more.



Voltage : 3-9VDC

RPM : 90 - 300 no load

Max Current : 200mA

Wheel Diameter : 65mm

Shaft Length : 3.6mm



£3.50

(inc VAT £4.20)
Quantity
Quick View
High Speed Micro Motor

High Speed Micro Motor

N50

N50 High Speed Micro Motor



This micro motor works between 3.7 - 5V DC and spinning at between 27500 RPM @3.7V and 40000 RPM @5V under no load. It is very lightweight at only 10g making it very usefull for small projects, drones or other models.



Voltage : 3.7 - 5VDC

Speed : 27500 - 40000 RPM (no load)

Current : 280mA

Length : 25.5mm Body + 9.5mm Shaft

Width : 10mm x 12mm

Shaft Diameter : 1.0mm

Weight : 10g

£3.00

(inc VAT £3.60)
Quantity
Quick View
L298N Motor Driver Module

L298N Motor Driver Module

L298MOD

L298N Motor Driver Module

This is a L298N-based motor driver module capable of accepting a logic input from an Arduino (or a similar microcontroller) in order to control bipolar stepper motors or DC motors. The module has screw terminal connectors for power input and output and a 6 pin header connector for logic input and motor control.

Connecting the jumper links (from ENA and ENB to 5V) allows the motors to spin at full speed, while removing them will stop the motors (unless the ENA and ENB pins are connected to the Arduino for PWM speed control).

Voltage : 5VDC
Logic current: 0mA - 36mA
Size: 43mm x 43mm x 27mm

£4.00

(inc VAT £4.80)
Quantity
Quick View
Miniature Hobby Motor 3V-6V DC, 8000 RPM (130 DC Size)

Miniature Hobby Motor 3V-6V DC, 8000 RPM (130 DC Size)

HMOT

130 DC High Speed Miniature Hobby Motor



This hobby motor works between 3V - 6V DC and is very lightweight at only 12g making it very useful for small projects, drones or other devices.



Voltage : 3V - 6VDC

Current : 350mA - 400mA

Dimensions: 28 x 15 x 21mm

Shaft Diameter: 2.0mm

Shaft Length: 9mm

Weight : 12g

£1.50

(inc VAT £1.80)
Quantity
Quick View
Stepper Motor 28BYJ-48 with ULN2003 Driver Board

Stepper Motor 28BYJ-48 with ULN2003 Driver Board

28BYJ-48

28BYJ-48 Stepper Motor wih ULN2003 IC & Driver Board


This is a 4 phase 5VDC stepper motor with 4 coils, with a step angle of either 11.25 or 5.625 degrees giving it 32 or 64 steps on the motor using either half or full steps. It also has a 1:64 gearbox built in making the steps at the shaft either 2048 or 4096. It is supplied with a ULN2003 driver board.

Voltage : 5VDC
Step angle : 5.625 1/64
Max Current : 300mA
Diameter : 28mm
Height : 19mm
Shaft Length : 8mm
Driver PCB Size : 32x35mm

£4.50

(inc VAT £5.40)
Quantity
Quick View
DS3225 Servo Motor 25kg/cm 180 Degrees

DS3225 Servo Motor 25kg/cm 180 Degrees

DS3225

DS3225 High Torque Servo 25kg/cm

Dimensions: 40 * 20 * 46mm

Working voltage: 3.7-7.2VDC

Working torque: 25.0kg/cm

Corner angle: 180 °

    £14.00

    (inc VAT £16.80)
    Quantity
    Quick View
    DS3240 Servo Motor 40kg/cm 180 Degrees

    DS3240 Servo Motor 40kg/cm 180 Degrees

    DS3240

    DS3240 High Torque Servo 40kg/cm

    Dimensions: 40 * 20 * 46mm

    Working voltage: 3.7-7.2VDC

    Working torque: 40.0kg/cm

    Corner angle: 180 °

      £22.00

      (inc VAT £26.40)
      Quantity
      Quick View
      MG996R Servo 180 Degrees

      MG996R Servo 180 Degrees

      MG996R

      MG996R Micro Servo for Models, RC,  Arduino and other microcontroller projects

      • High Torque Performance for RC Applications - The MG996R servo delivers strong torque ideal for demanding applications in 1/8 and 1/10 scale RC cars, helicopters, boats, and robots. Its robust output ensures reliable operation under heavy loads.
      • Digital Servo with Metal Gear Construction - Equipped with a metal gear, this digital servo offers enhanced durability and resistance to wear. The metal gear improves performance and longevity compared to plastic alternatives.
      • Optimized Voltage Range: 4.8V to 6.0V - Designed to operate efficiently within a 4.8V to 6.0V voltage range, this servo ensures stable performance when used with compatible power sources such as standard RC battery packs.
      • Compatible with Futaba and JR Systems - This servo is engineered for seamless integration with popular RC systems including Futaba and JR receivers, making it a versatile choice for hobbyists using these brands.
      • Universal Use with Arduino & other microcontrollers - Fully compatible with Arduino UNO and other microcontroller platforms, the MG996R is ideal for robotics projects requiring precise control and reliable movement.

      Specification:

      Dimension : 40mm x 19mm x 43mm
      Weight : 56g
      Operating Speed : 0.17sec / 60 degrees (4.8V no load)
      Operating Speed : 0.13sec / 60 degrees (6.0V no load)
      Stall Torque : 13 kg-cm (180.5 oz-in) at 4.8V
      Stall Torque : 15 kg-cm (208.3 oz-in) at 6V
      Operation Voltage : 4.8 - 7.2Volts
      Gear Type: All Metal Gears

      £6.00

      (inc VAT £7.20)
      Quantity
      Quick View
      SG90 Micro Servo 9g

      SG90 Micro Servo 9g

      SG90

      SG90 Micro Servo for Arduino and other microcontroller projects



      This micro servo is the most popular 9g servo in the world.

      It is used for Radio Control models, robotics plus many other uses.

      Compatible with Arduino and other microcontroller projects.

      Supplied with 3 different servo horns and fixing screws.





      Voltage : 5VDC

      Speed : 60 Degrees in 0.12 second

      Torque : 1.8kg/cm

      Wire Length : 150mm

      Size : 23x12.2x29mm

      Weight : 9g

      £2.75

      (inc VAT £3.30)
      Quantity
      Quick View
      Rotary encoder module for Arduino KY-040

      Rotary encoder module for Arduino KY-040

      KY040

      Rotary encoder module for Arduino and other microcontroller projects

      This module uses a 30 position rotary encoder with push switch.
      The rotary encoder works by having 2 switches (A&B) for each position that are slightly offset, indicating the direction of rotation by detecting if "A" switches before or after "B".

      Voltage : 5VDC
      Size 19x15mm

      £2.50

      (inc VAT £3.00)
      Quantity
      Quick View
      Playstation 5 (PS5) replacement hall effect joystick

      Playstation 5 (PS5) replacement hall effect joystick

      JYP5

      Playstation 5 (PS5) replacement hall effect joystick

        If your Playstation 5 controller has a mind of it's own (stick drift) or has physical damage to a joystick then don't just buy a new one, fix it. These new "hall effect" replacement joysticks work with tiny magnets and a magnetic strength sensor to replace the old style metal contact moving over a carbon track type. Replacing your old joystick with one of these will not only get it working properly again but make it better than when it was new with stick drift being a thing of the past.

      • High Precision Control - Experience high-response accuracy with our hall effect joysticks, designed without the common issues of carbon film joystick jitter. The enhanced
        sensitivity of the Hall effect sensor provides an unmatched control precision, perfect for FPS shooters and any game demanding fine-tuned input
      • No "Stick Drift" thanks to Hall effect magnetic technology
      • Durable and  Reliable - hall effect technology eliminates physical contact preventing wear and tear and ensuring longevity



      £2.50

      (inc VAT £3.00)
      Quantity
      Quick View
      Playstation 4 (PS4) replacement hall effect joystick

      Playstation 4 (PS4) replacement hall effect joystick

      JYP4

      Playstation 4 (PS4) replacement hall effect joystick

        If your Playstation 4 controller has a mind of it's own (stick drift) or has physical damage to a joystick then don't just buy a new one, fix it. These new "hall effect" replacement joysticks work with tiny magnets and a magnetic strength sensor to replace the old style metal contact moving over a carbon track type. Replacing your old joystick with one of these will not only get it working properly again but make it better than when it was new with stick drift being a thing of the past.

      • High Precision Control - Experience high-response accuracy with our hall effect joysticks, designed without the common issues of carbon film joystick jitter. The enhanced
        sensitivity of the Hall effect sensor provides an unmatched control precision, perfect for FPS shooters and any game demanding fine-tuned input
      • No "Stick Drift" thanks to Hall effect magnetic technology
      • Durable and  Reliable - hall effect technology eliminates physical contact preventing wear and tear and ensuring longevity



      £2.50

      (inc VAT £3.00)
      Quantity
      Quick View
      Xbox 1 replacement hall effect joystick

      Xbox 1 replacement hall effect joystick

      JYX1

      Xbox 1 replacement hall effect joystick

        If your Xbox 1 controller has a mind of it's own (stick drift) or has physical damage to a joystick then don't just buy a new one, fix it. These new "hall effect" replacement joysticks work with tiny magnets and a magnetic strength sensor to replace the old style metal contact moving over a carbon track type. Replacing your old joystick with one of these will not only get it working properly again but make it better than when it was new with stick drift being a thing of the past.

      • High Precision Control - Experience high-response accuracy with our hall effect joysticks, designed without the common issues of carbon film joystick jitter. The enhanced
        sensitivity of the Hall effect sensor provides an unmatched control precision, perfect for FPS shooters and any game demanding fine-tuned input
      • No "Stick Drift" thanks to Hall effect magnetic technology
      • Durable and  Reliable - hall effect technology eliminates physical contact preventing wear and tear and ensuring longevity



      £2.50

      (inc VAT £3.00)
      Quantity
      Quick View
      Nintendo Pro Controller replacement hall effect joystick

      Nintendo Pro Controller replacement hall effect joystick

      JYNT

      Nintendo Switch Pro Controller replacement hall effect joystick

        If your Nintendo Switch Pro controller has a mind of it's own (stick drift) or has physical damage to a joystick then don't just buy a new one, fix it. These new "hall effect" replacement joysticks work with tiny magnets and a magnetic strength sensor to replace the old style metal contact moving over a carbon track type. Replacing your old joystick with one of these will not only get it working properly again but make it better than when it was new with stick drift being a thing of the past.

      • High Precision Control - Experience high-response accuracy with our hall effect joysticks, designed without the common issues of carbon film joystick jitter. The enhanced
        sensitivity of the Hall effect sensor provides an unmatched control precision, perfect for FPS shooters and any game demanding fine-tuned input
      • No "Stick Drift" thanks to Hall effect magnetic technology
      • Durable and  Reliable - hall effect technology eliminates physical contact preventing wear and tear and ensuring longevity



      £2.50

      (inc VAT £3.00)
      Quantity
      Quick View
      Bracket for Geared Motors

      Bracket for Geared Motors

      GMBKT

      Bracket for Geared Motors

             This bracket is for use with the range of geared motors bellow:

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £0.50

      (inc VAT £0.60)
      Quantity
      Quick View
      N20 Geared Motor 3V 15rpm

      N20 Geared Motor 3V 15rpm

      GM3V15

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 3V 30rpm

      N20 Geared Motor 3V 30rpm

      GM3V30

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 3V 60rpm

      N20 Geared Motor 3V 60rpm

      GM3V60

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 3V 150rpm

      N20 Geared Motor 3V 150rpm

      GM3V150

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 3V 300rpm

      N20 Geared Motor 3V 300rpm

      GM3V300

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 3V 600rpm

      N20 Geared Motor 3V 600rpm

      GM3V600

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 3V 1000rpm

      N20 Geared Motor 3V 1000rpm

      GM3V1000

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 6V 15rpm

      N20 Geared Motor 6V 15rpm

      GM6V15

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2 0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 6V 30rpm

      N20 Geared Motor 6V 30rpm

      GM6V30

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 6V 60rpm

      N20 Geared Motor 6V 60rpm

      GM6V60

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2

      0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 6V 150rpm

      N20 Geared Motor 6V 150rpm

      GM6V150

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2 0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 6V 300rpm

      N20 Geared Motor 6V 300rpm

      GM6V300

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2 0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 6V 600rpm

      N20 Geared Motor 6V 600rpm

      GM6V600

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2 0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Quick View
      N20 Geared Motor 6V 1000rpm

      N20 Geared Motor 6V 1000rpm

      GM6V1000

      N20 Geared Micro Motor

              This range of mini geared motors are available in 3 different voltages (3V, 6V & 12V) and each voltage is available in 7 different gear ratios giving various RPMs from 15 to 1000 RPM. They are very lightweight at only 9g making them very useful for small many projects such as cars, robotics, doors or anything that needs to move.

      Please see the table bellow and click on the part number on the left to order the motor you require.

      Model
      Voltage Range
      Rated Voltage
      Non-loaded Rotation speed [RPM]
      Non-loaded Current [A]
      Loaded Rotation speed [RPM]
      Loaded Current [A]
      Loaded Torque [Kg x Cm]
      Locked-rotor Torque [Kg x Cm]
      Locked-rotor Current [A]
      GM3V15 1.5 - 5 3 15 0.01 10 0.04 0.5 4 1
      GM3V30 1.5 - 5 3 30 0.01 25 0.02 0.26 2 1
      GM3V60 1.5 - 5 3 60 0.01 50 0.02 0.2 1.5 1
      GM3V150 1.5 - 5 3 150 0.01 120 0.03 0.1 0.8 0.23
      GM3V300 1.5 - 5 3 300 0.14 250 0.2 0.07 0.56 0.5
      GM3V600 1.5 - 5 3 600 0.1 500 0.03 0.05 0.4 0.1
      GM3V1000 1.5 - 5 3 1000 0.03 700 0.08 0.02 0.3 0.3
      GM6V15 3 - 9 6 15 0.01 10 0.02 0.4 2 0.1
      GM6V30 3 - 9 6 30 0.02 25 0.04 1.2 10 1
      GM6V60 3 - 9 6 60 0.03 50 0.05 0.6 3.2 1
      GM6V150 3 - 9 6 150 0.03 120 0.05 0.35 2.4 0.25
      GM6V300 3 - 9 6 300 0.03 240 0.04 0.2 1.6 0.2
      GM6V600 3 - 9 6 600 0.16 500 0.23 0.15 1 0.56
      GM6V1000 3 - 9 6 1000 0.01 800 0.03 0.06 0.4 0.16
      GM12V15 6 - 12 12 15 0.01 10 0.04 1.2 4.6 1
      GM12V30 6 - 12 12 30 0.01 25 0.04 1.2 7 1
      GM12V60 6 - 12 12 60 0.04 40 0.06

      1.8

      		 16 1
      GM12V150 6 - 12 12 150 0.11 120 0.04 1 7 1
      GM12V300 6 - 12 12 300 0.05 240 0.09 0.6 4 0.3
      GM12V600 6 - 12 12 600 0.03 500 0.07 0.4 3.2 0.2
      GM12V1000 6 - 12 12 1000 0.19 800 0.28 0.3 2.4 0.6

      £4.50

      (inc VAT £5.40)
      Quantity
      Page of 2
      Categories
      Manufacturers
      Recently Viewed
      Bestsellers
      Bestsellers
      Recently Viewed
