Door Entry

10.1" Touchscreen Monitor for DNAKE Door Entry Systems

Using the Android 10 operating system, this DNAKE SIP-based indoor monitor provides high-definition audio and video communication with Door Station and room-to-room communication via SIP 2.0 protocol. It also allows integration with 3rd party software, offering an integrated security solution.

Specifications:

Resolution: 1280 * 800
Video Codec: H.264
System Memory: 2GB
Storage Capacity: 8GB (can be upgraded via the TF card slot)
Power: PoE or 12V DC (2A)
Standby power usage: 3W
Rated Power: 10W
Wi-Fi: IEEE 802.11 b/g/n,@2.4GHz (Optional)
Dimensions: 264.3 x 160 x 11.8 mm
Supported Network Protocols: SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP

For full datasheet, click on the "Files" tab

7 Inch Touchscreen Monitor for DNAKE Door Entry Systems

The DNAKE E217 provides multiple functions, including audio and video intercom, emergency call and security alarm, etc. It also supports communication via SIP 2.0 protocol with IP phone and IP-PBX.

Features:
• 7 inch capacitive touch screen
• Powered by PoE or 12V DC power supply
• WiFi enabled
• Supports micro-SD cards

Specifications:
Screen resolution: 1024 x 600
Ethernet connection: 1 x RJ45 10/100Mbps (adaptive)
Doorbell input: 8
Alarm input: 8
Power consumption: 9W (rated), 2W (standby)
Dimensions: 195mm x 130mm x 14.5mm

For full datasheet, click on the "Files" tab

1 Button Compact SIP Video Door Phone

The DNAKE S212 allows you to make calls to an indoor monitor station (such as the H618W) at the touch of a button, or using an RFID access card.

Features:
• 1280 x 720 HD camera
• Built-in speaker and microphone
• Aluminium front panel
• Motion detection
• Tamper alarm
• WiFi and bluetooth enabled

Specifications:
IP rating: IP65
Relay outputs: 2
Ethernet connection: 1 x RJ45, 10/100 Mbps (adaptive)
Camera viewing angle: 110°(H) x 60°(V) x 125°(D)
Frame rate: 25fps
Supported protocols: ONVIF, SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPv4, ARP, ICMP
Dimensions (inc. frame): 210mm x 120mm x 32mm

For full datasheet, click on the "Files" tab

1 Button Compact SIP Video Door Phone

The DNAKE C112 allows you to make calls to an indoor monitor station (such as the H618W) at the touch of a button, or using a 13.56MHz RFID access card.

Features:
• Compact design
• 2MP (1080p) full HD camera
• Built-in speaker and microphone
• Motion detection
• Tamper alarm
• WiFi and bluetooth enabled

Specifications:
IP Rating: IP65
Relays: 1
Ethernet Connection: 1 x RJ45, 10/100 Mbps (adaptive)
Camera Viewing Angle: 100°(H) x 60°(V) x 125°(D)
Frame Rate: 25fps
Supported Protocols: ONVIF, SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPv4, ARP, ICMP
Dimensions: 130mm x 50mm x 28mm

1 Button Compact SIP Video Door Phone

The DNAKE S212 allows you to make calls to an indoor monitor station (such as the H618W) at the touch of a button, or using an RFID access card.

Features:
• 1280 x 720 HD camera
• Built-in speaker and microphone
• Aluminium front panel
• Motion detection
• Tamper alarm
• WiFi and bluetooth enabled

Specifications:
IP rating: IP65
Relay outputs: 2
Ethernet connection: 1 x RJ45, 10/100 Mbps (adaptive)
Camera viewing angle: 110°(H) x 60°(V) x 125°(D)
Frame rate: 25fps
Supported protocols: ONVIF, SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPv4, ARP, ICMP
Dimensions: 168mm x 88mm x 34mm

For full datasheet, click on the "Files" tab
