Peerless by Tymphany 100W HiFi Ring Radiator Tweeter XT25SC90-04
|
XT25SC90-04 Peerless by Tymphany HiFi Ring Radiator 100W Max.
Transducer Size: 25 mm
DC Resistance (Re): 3.2 Ω
Resonance Frequency (Fs): 830 Hz
Sensitivity @ 2.83V/1m: 90.2 dB
Sensitivity @ 1W/1m: 87.2 dB
Rated Noise Power (IEC 268-5): 100 W
Test Spectrum Bandwidth: 2000 - 20000 Hz
Effective Piston Area (Sd): 7.07 cm2
Moving Mass (Mms): 0.359 g
Motor Force Factor (Bl): 2.27 Tm
Motor Efficiency (β) 1.61 (Bl)2 / Re
Voice Coil Inner Diameter: 25.8 mm
Gap Height (Hag): 2 mm
Maximum Linear Excursion (Xmax): 0.867 mm
Minimum Impedance (Zmin): 3.6 Ω
Voice Coil Inductance (Le): 0.021 mH
Mechanical Q Factor (Qms): 7.36
Electrical Q Factor (Qes): 1.17
Total Q Factor (Qts): 1
Suspension Compliance (Cms): 100 μm/N
Net Weight: 0.074 kg
Equivalent Volume (Vas): 0.007 L
|
