Rean Powercon RCAC3I Mains INPUT Cable Connector

Rean Powercon RCAC3I Mains INPUT Cable Connector

Technical Specification:

Electrical

• Number of contacts 2 + PE
• Rated current per contact 16 A / 20 A RMS
• Rated Voltage 250 V / 127 V AC
• Dielectric strength (peak) 4 kV ac
• Contact resistance ≤ 3 mΩ
• Insulation resistance (after dampheat, IEC 68-2-30) > 1 GΩ

Mechanical

• Retention method Twist lock
• Cable O.D. range 6 -15 mm
• Wiring Cable Screw type terminals, wire size 2.5 mm² / 12 AWG
• Wiring Receptacle Flat tabs for FASTON® (4.8 x 0.5 mm) or soldering

Material

• Cable connector contacts Brass, Ag plated
• Receptacle contacts Bronze, Ag plated
• Chucks POM

Environmental

• Flammability UL94 V-0
• Temperature range -30 °C to +80 °C
• Protection class (mated) IP 20
• Safety Requirments EN / IEC61984
• Solderability complies with IEC68-2-20
