Hammond 1550C High Quality, Heavy Duty Diecast Aluminium Box

Easy to drill for switches and sockets etc.

For housing & screening electronic circuits.

IP54 rating.

External Dimensions: 115 x 90 x 51mm

Hammond 1550G High Quality, Heavy Duty Diecast Aluminium Box

Easy to drill for switches and sockets etc.

For housing & screening electronic circuits.

IP54 rating.

External Dimensions: 222 x 146 x 55mm

High Quality 4mm chassis/panel socket rated at 10A with solder tag. Insulated Black

Total Length: 31mm:

Nut: M8 8mm cut-out

High Quality 4mm chassis/panel socket rated at 10A with solder tag. Insulated Red

Total Length: 31mm:

Nut: M8 8mm cut-out

High Quality Silicone Multimeter Test Leads with Crocodile Clips

Cable Length: 880mm
Total length: 1050mm
Red: positive   Black: negative
Maximum Voltage: 1000V Max. Current 20A

Features:

• Gold plated probe tips for better contact and corrosion resistance
• Cat. III rating (croc clips are Cat. II)
• Supplied with removable probe protection caps
• Shrouded connectors
• Comfortable rubber grip
• Fit most multimeters

High Quality Silicone Multimeter Test Leads with 4mm Shrouded Plugs


Cable Length: 880mm
Total length: 1050mm
Red: positive   Black: negative
Maximum Voltage: 1000V Max. Current 20A

Features:

• Gold plated tips for better contact and corrosion resistance
• Cat. III rating
• Supplied with removable probe protection caps
• Shrouded connectors
• Comfortable rubber grip
• Fit most multimeters

2 + 2 Way Easy to use Installation Terminal Block

A simple to use terminal block (splicing connector). Simply lift the lever, insert a stripped wire and then close the lever to make a reliable and electrically safe connection between 2 wires.

different colours are individually isolated

Rated Voltage: 240V
Rated Current: 32A
flame retardant material
colour coded handles

2 Way Easy to use Inatallation Terminal Block

A simple to use terminal block (splicing connector). Simply lift the blue lever, insert a stripped wire and then close the lever to make a reliable and electrically safe connection between 2 wires.

Rated Voltage: 400V
Rated Current: 32A
Wire Cross Section: 0.14 - 4mm²
Insulation: PA66 Nylon
Contact Plating: Phosphor Copper

3 + 3 Way Easy to use Installation Terminal Block

A simple to use terminal block (splicing connector). Simply lift the lever, insert a stripped wire and then close the lever to make a reliable and electrically safe connection between 2 wires.

different colours are individually isolated

Rated Voltage: 240V
Rated Current: 32A
flame retardant material
colour coded handles

3 Way Easy to use Inatallation Terminal Block

A simple to use terminal block (splicing connector). Simply lift the blue lever, insert a stripped wire and then close the lever to make a reliable and electrically safe connection between 3 wires.

Rated Voltage: 400V
Rated Current: 32A
Wire Cross Section: 0.14 - 4mm²
Insulation: PA66 Nylon
Contact Plating: Phosphor Copper

4 Way Easy to use Inatallation Terminal Block

A simple to use terminal block (splicing connector). Simply lift the blue lever, insert a stripped wire and then close the lever to make a reliable and electrically safe connection between 4 wires.

Rated Voltage: 400V
Rated Current: 32A
Wire Cross Section: 0.14 - 4mm²
Insulation: PA66 Nylon
Contact Plating: Phosphor Copper

5 Way Easy to use Inatallation Terminal Block

A simple to use terminal block (splicing connector). Simply lift the blue lever, insert a stripped wire and then close the lever to make a reliable and electrically safe connection between 5 wires.

Rated Voltage: 400V
Rated Current: 32A
Wire Cross Section: 0.14 - 4mm²
Insulation: PA66 Nylon
Contact Plating: Phosphor Copper

Intelligent Battery Charger for Li-Ion batteries including 18650

• Automatic 0.5A Fast Charge and Trickle Charge

• LED indicators for charging status

• Charges 10440, 17335, 18650, 14500, 14650, 16340, 17500, 17670, 18350, 18500, 18700, 22650, 25500, 26650 Batteries

• Plugs into a standard USB socket like a mobile phone charger or PC

• overcharging protection, short-circuit protection and protection against reverse polarity

• Dimensions:  92 x 40 x 32mm

• Power Required 5V @ 1A (will work on 0.5A at a lower charging rate)

Batteries not included

LED Lighthouse Solder Practice Kit

This simple flashing LED circuit is great for learning how to solder or to polish up on your soldering skills. It uses a 555 timer in the astable configuration to flash the LEDs continuously. The rate of flashing can be changed by adjusting the variable trimmer potentiometer R2 (f ≈ 0.3Hz-30Hz). It can be powered by a 9V PP3 battery (not supplied).

The kit is supplied with Yellow LEDs by default but you can choose Red, Blue, Green or White LEDs from the drop-down list above.

Miniature Toggle Switch DPDT Centre-off - Biased Momentary One Way. Latching the other way.

125VDC 5A max. 33 x 13 x 12mm M6 Nut.

Relay Single Pole Changeover 12V 3A @ 125VDC 400 ohms. Operating Range 9V to 14V

Relay Single Pole Changeover 12V. 3A @ 125VDC 1600 ohms. Operating Range 18V to 36V

Monacor - Super High Definition Bipolar Audio Axial Capacitor

Extra Low Loss Polypropylene Film 1uF 250V. ±5% Tolerance

Size 9x31mm

Datasheet

Battery holder for single N cell. 13.5 x 35mm approx. 14mm PCB pins.

Fits N cells, MN21, GP23A, VR22, A22, A23, LN08, L1028 etc

Non-Contact Metal Detector Kit

Basic metal detector sensor module with buzzer and LED alarm. Will detect metal at a range of up to 60mm, including through soil, cothing, etc. Requires an input voltage of 3-5V DC, which can be supplied to the module via the 2 pin screw terminal (e.g. battery pack, USB, power supply). The sensitivity can be adjusted by the VR1 potentiometer.





Nylon Nut. M3 (3mm dia Metric thread) 10 pack

Nylon Cheesehead Screw Slotted. M3 (3mm dia Metric thread) 12mm long. 10 pack

Nylon Cheesehead Screw Slotted. M3 (3mm dia Metric thread) 20mm long 10 pack

Very High Quality Porcelain (Ceramic) Octal Valve Base (Tube Socket). 8 pins. Heavy Gold Plating. Test Voltage: 1600V, Insulation resistance >10,000M ohms, Contact resistance: < 10 milliohms. For many Large Output Valves inc EL34, KT66, KT88, 6L6, 6551, 5881, GZ34, 5U4G. Versatile flange can be mounted above or below the chassis.

A Very High Quality Porcelain (Ceramic) Octal Valve Base (Tube Socket) 8 pins. Durable Plating.

• Test Voltage: 1600V,
• Insulation resistance >10,000M ohms,
• Contact resistance: < 10 milliohms.
• For many Large Output Valves inc EL34, KT66, KT88, 6L6, 6551, 5881, GZ34, 5U4G.
• Versatile flange can be nounted above or below the chassis.

Very High Quality Porcelain (Ceramic) Octal Valve Base (Tube Socket), 8 pins. Heavy Gold Plating. Test Voltage: 1600V, Insulation resistance >10,000M ohms, Contact resistance: < 10 milliohms. For many Large Output Valves inc EL34, KT66, KT88, 6L6, 6551, 5881, GZ34, 5U4G. Printed Circuit (PCB) type.

Cable Ties 100mm Long. Non-reusable. Black 100 pack

Black Cable Ties 200mm Long. Non-reusable. 100 pack

Cable Ties 300mm Long. Non-reusable. Black 100 pack

Cable Ties 100mm Long. Non-reusable. White 100 pack
