Multifunction PCB Rule - 30cm

Handy and accurate multifunction true-zero rule with metric scale, fractional and decimal imperial scales, metric and imperial gauge, protractor and other functions.

Features:
• Accurate scale (metric, imperial - fractional and decimal)
• Capacitor tolerance code table
• AWG and metric drill gauge
• Protractor
• Common op-amp configurations with formulas
• Trace width
• SMD outlines (see list below):

This rule also has the footprints the following SMD outlines:

Transistor outlines: SOT223, SOT89, SOT23, SOT323, SOT564, SOT553, SOT143, TSOP-5, TO252, TO263
Diode outlines: SOD523, SOD323, SOD110, SOD123, SOD80C, SOD106, SOD106A, MINIMELF, MICROMELF, DO214AC, DO214BA, DO214AA, DO214AB
IC packages: TFBGA, SO14, SSOP-28, VDFN-8
Resistors, Capacitors, Inductors, etc.: 0201, 0402, 0603, 0805, 1206, 1210, 2010, 2512, 4527
Capacitors: A, B, C, D, E, F, G, KA, KB, KC, KD, KE

Non contact Infrared Thermometer with backlit screen and single point laser positioning

This non contact thermometer is a very useful tool for getting a fast and accurate measurement of temperature in situations where it is not practical to use a conventional thermometer. From checking for hot spots on PCBs or checking for bad electrical connections to checking the food on your BBQ with many other uses in between, you will find this thermometer a valuable addition to your collection.

Specs

Temperature Range: -50 to 400C

Accuracy:

-50 - 0C +-2% (+-3C)

0 - 50C +-1.5% (+-1.5C)

50 - 400C +-2% (+-3.5C)

12:1 Object distance ratio

Non contact Infrared Thermometer with backlit screen and multi point laser positioning

This non contact thermometer is a very useful tool for getting a fast and accurate measurement of temperature in situations where it is not practical to use a conventional thermometer. From checking for hot spots on PCBs or checking for bad electrical connections to checking the food on your BBQ with many other uses in between, you will find this thermometer a valuable addition to your collection.

Specs

Temperature Range: -50 to 600C

12:1 Object distance ratio

16mm diameter Dual Control Pot with knurled & Slotted 6mm dia spindle. PCB Pins 5mm spacing. 50K Log

15mm Shaft

Relay Single pole changeover 12V 16A @ 24VDC, 16A @ 240VAC. 275 ohms. Operating Range 9V-13V. Silver Cadmium Oxide Contacts.

9.5mm 20 Turn Precision Cermet Preset Top adjust. 500 ohms

Red & Black 2 core Fig 8 Power Cable For Loudspeaker & other uses 2.6mm x 2 diameter. Priced per 100 Metre Drum

Also available in 1 Meter cuts - Please go to ZL27

Silicone Mica Washer TO3 devices

Silicone Washer and Bush kit for TO218 devices

Contents:

1 Silicone Washer

1 Bush

Silicone Washer and Bush kit for TO220 devices

Contents:

1 Silicone Washer

1 Bush

FR4 High Quality Single-sided copper-clad 1.6mm Epoxy Glass Fibre Board. 100 X 160mm.

305g/m copper. Suitable etchant Ferric Chloride.

FR4 High Quality Single-sided copper-clad 1.6mm Epoxy Glass Fibre Board. 100 X 220mm.

305g/m copper. Suitable etchant Ferric Chloride.

FR4 High Quality Single-sided copper-clad 1.6mm Epoxy Glass Fibre Board. 233 X 220mm.

305g/m copper. lSuitable etchant Ferric Chloride.

Single Sided Photo Board. Laminate positive etch-resist UV sensitive board. Use with Photo-Developer. 100 x 160mm

Single Sided Photo Board. Laminate positive etch-resist UV sensitive board. Use with Photo-Developer. 100 x 220mm

Solderless Terminal Crimping Tool - Compatible with Dupont Connectors and Open Barrel Crimps

• Compatible with : Dupont type crimp Connectors, Open Barrel Lucar type and various other Open Barrel type Crimps

Solderless Terminal Crimping Tool - Compatible with JST Connectors

• Compatible with : XH2.54, XH3.96, PH2.0, PX, KK254 and other JST and Molex Connectors



Spring Clip Microphone Holder  with 3/8" to 5/8" Thread Adaptor
Black plastic Sprung-Jaw holder for mikes up to 30mm diameter

SSR-25 DA Solid State Relay 25A

SSR-40 DA Solid State Relay 40A

Technical Specifications

Input Operating Voltage: 3-32V DC
Output Operating Voltage: 24-380V AC
Trigger Current: 7.5mA @ 12V
Dielectric Strength: ≥2.5KV AC/1min.
Isolation Strength  ≥50MΩ/500V DC
Control Method: Zero Cross Trigger
Voltage Drop: 1.6V @ 25°
Operating temperature: -20°C to +80­°C
Weight: 105g



SSR-60 DA Solid State Relay 60A

Technical Specifications

Input Operating Voltage: 3-32V DC
Output Operating Voltage: 24-380V AC
Trigger Current: 7.5mA @ 12V
Dielectric Strength: ≥2.5KV AC/1min.
Isolation Strength  ≥50MΩ/500V DC
Control Method: Zero Cross Trigger
Voltage Drop: 1.6V @ 25°
Operating temperature: -20°C to +80­°C
Weight: 105g



STRONG & USEFUL CRIMP & MULTI PURPOSE TOOL
For SOLDERLESS RED/BLUE/YELLOW Terminals. Hardened Tool-Steel Complete with Wire Cutter/Stripper & Screw Cutter. Solid heavy tool.

PTFE (Teflon) Washer and 2 bushes for TO66 devices

16 Camera 4 Megapixel High Definition Night & Day White Eyeball Dome CCTV System with 30m Night Vision
All our systems are bespoke; they are not pre-boxed kits. You can select any mix of our  cameras. Just phone  020 8452 0161. All systems include a highly discounted bundle.

• 4MP gives stunning & detailed colour evidence
• Incredibly Advanced Video Content Analysis (VCA) - Facial Recognition, Crowd Density, Area Intrusion, People Flow Counter, Object Removal to name but a few
• Simple Mobile/PC/Laptop viewing with Internet & Cloud Technology
• Very High Efficiency Ultra 265 codec

Cameras are suitable for Outdoor (IP67)  & Indoor Use. All Cameras have 30M Smart Night Vision

Features:
*  Realtime Live & Recorded Images
*  View on PCs, Laptops, iPhones, iPads, Android Phones and Tablets
*  SD Card Slot on each camera for edge recording (upto 256GB)
*  Built-in microphone on each camera
*  Video Content Analysis includes:
         •Entering/leaving area
         •Out of focus detection
         •Scene change detection
         •Object removal
         •Object left behind
         •Auto tracking (for PTZ cameras)
         •People flow counter
         •Crowd density
         •Face detection
         •Tripwire crossing detection
         •Area intrusion detection
         •Area leaving detection
*  Quiet Running Fanless 16 Channel NVR with VGA and HDMI video output
*  4 Megapixel High Definition Eyeball Dome Cameras
*  Supplied with 1TB HDD,  with option for 2TB, 4TB, 6TB or 8TB.
*  Can be set to Real-time, Time Lapse, VCA or Programmed Timer.

Full Datasheets can be found below:

NVR

Camera

Contents of Package:
16 x 4 Megapixel White Eyeball Dome Cameras IPC3614LE-ADF28K
1 x Uniview Ultra High Definition 8 Megapixel 16 Channel NVR NVR302-16S2-P16
16 x 20m CAT6 Leads
1 x 1m HDMI lead for NVR to Screen

HD Monitor available as an option

Hard Drive Selection Guide
The following times are based on high quality recordings.
These times can be greatly extended by changing recording quality settings or by using motion detection/timed recording.

16 cameras at real-time:

1TB:      2 days
2TB:             3 1/2 days
4TB:             7 days
6TB:             10 1/2 days
8TB:             14 days
12TB:           21 days
16TB:           28 days

16 Camera 8 Megapixel (4k) Ultra High Definition Night & Day White Eyeball Dome CCTV System with ColourHunter Night Vision
All our systems are bespoke; they are not pre-boxed kits. You can select any mix of our  cameras. Just phone  020 8452 0161. All systems include a highly discounted bundle.

• 8MP gives stunning & detailed colour evidence
• Incredibly Advanced Video Content Analysis (VCA) - Facial Recognition, Crowd Density, Area Intrusion, Object Removal to name a few
• Simple Mobile/PC/Laptop viewing with Internet & Cloud Technology

• Free UK-based phone and in-store support

• No subscription required!
• Very High Efficiency Ultra 265 codec

Cameras are suitable for Outdoor & Indoor Use. All Cameras have 30M Colour and Infrared Night Vision

Features:
*  Realtime Live & Recorded Images
*  View on PCs, Laptops, iPhones, iPads, Android Phones and Tablets
*  Built-in microphone on each camera
*  Video Content Analysis includes:
         •Entering/leaving area
         •Out of focus detection
         •Scene change detection
         •Object removal
         •Object left behind
         •Auto tracking (for PTZ cameras)
         •People flow counter
         •Crowd density
         •Face detection
         •Tripwire crossing detection
         •Area intrusion detection
         •Area leaving detection
*  Quiet Running Fanless 16 Channel NVR with VGA and HDMI video output
*  8 Megapixel Ultra High Definition (4k) Eyeball Dome Cameras
*  Supplied with 1TB HDD,  with option for 2TB, 4TB, 6TB or 8TB.
*  Can be set to Real-time, Time Lapse, VCA or Programmed Timer.

Full datasheet and user manuals for both the cameras and the NVR can be found in the "Files" tab above

Contents of Package:
16 x Uniview 8 Megapixel Colour White Eyeball Dome Cameras
1 x Uniview Ultra High Definition 8 Megapixel 16 Channel DVR
16 x 25m CAT6 Leads
1 x 1m HDMI lead for DVR to Screen

HD Monitor available as an option

Hard Drive Selection Guide
The following times are based on high quality recordings
After this period the DVR will start to over-write old events.


Approximate Hard Drive Recording Times

16 cameras at real-time:

1TB:         1 day
2TB:             2 days
4TB:             3 1/2 days
6TB:             5 1/4 days
8TB:             7 days
