180MHz Dual Channel Digital Phosphor Oscilloscope with Built-in Function Generator

DPOX180H 180MHz Dual Channel Digital Phosphor Oscilloscope with Function Generator

The DPOX180H is a small but mighty portable digital phosphor oscilloscope (DPO) with a bandwidth of 180MHz and high sampling rate of 500MS/s. Fully featured with a 2.8" IPS digital fluorescent display, 3000mAh Li-ion batttery, 50000wfm/s waveform refresh rate and 20MHz DDS function generator. All the benefits of a modern digital storage oscilloscope combined with the added benefits of an analogue oscilloscope display.

Package Contents:

1 * DPOX180H Digital Phosphor Oscillograph
2 * Matching 200MHz Probe (1X & 10X)
1 * 5V2A Power Adapter
1 * USB Data Line
1 * User Manual (English and Chinese)

Specifications:

Number of channels 2
Analog bandwidth 180MHZ
Maximum sampling rate 500MSPS
Input coupling DC/AC
Rise time 2.5nS
Storage depth 120Kpts
Input impedance 1MΩ-18PF
Vertical sensitivity 5mV ~ 10V(1X)
Time base range 5nS ~ 50S
DC accuracy ±2%
Time accuracy ±0.01%
Measurement range 40mV ~ 80V(1X)
Digital phosphor technolog support
Color temperature display support
Zoom scaling time base support
20M hardware bandwidth limitation support
Adjustable automatic bandwidth limitation support
X-Y mode support
FFT support
Cursor measurement Frequency/Period/Amplitude
Trigger detection Digital trigger
Trigger mode Auto/Single/Normal
Trigger edge Rising/Falling
Roll mode support
Screenshot storage 90
Waveform storage 250 groups
Capture signal 500
Parameter measurement 12 kinds
Signal generator 14 standard function signals
Auto-adjustment support
Waveform manager support
Waveform output support
High-voltageburnout protection support
Screen size 2.8 inches
Screen resolution 320x240
Display technology IPS full view
Expansion interface USB transmission interface
Auto power-off 5minutes-2hours
Firmware upgrade support
Charging requirements 5V 2A
Battery capacityï 3000mAh
Standby time 3.5 hours at full charge
Dimensions 135mmx90mmx40mm
