Black RG6 Foam Filled Coaxial Cable for TV & Satellite per Metre
|
White RG6 Polyethylene Filled Coaxial Cable for TV & Satellite per metre. Max length 50m RG6 75 ohms Filled Coaxial Cable - Copper Braid
75 Ohms RG6 coaxial cable constructed of solid copper clad steel conductor, PET dielectric, aluminium foil screen, copper braid and PVC sheath. The overall screen and braid significantly reduce noise penetration to the conductor making it suitable for digital, satellite and cable TV signal transmission.
For complete 100M Drums please go to ZR61H
Solid CCS conductor
PE dielectric
Binded aluminium screen
Aluminium braid
Supplied in 100m reel with metric cut markers
Screen Aluminium / PET foil
Dielectric 4.6mm foam PE
Cable diameter 6.6mm
Impedance 75 Ohms
Capacitance 54pF/m
Velocity factor 83 perecent
Return loss 5-400MHz 24dB min./100m
Return loss 450-1000MHz 20dB min./100m
Return loss 1000-2150MHz 16dB min./100m
Attenuation @ 5MHz 2.8dB max./100m
Attenuation @ 50MHz 5.1dB max./100m
Attenuation @ 100MHz 6.9dB max./100m
Attenuation @ 200MHz 10.1dB max./100m
Attenuation @ 400MHz 14.9dB max./100m
Attenuation @ 860MHz 20.1dB max./100m
Attenuation @ 1000MHz 22.2dB max./100m
Attenuation @ 1750MHz 29.6dB max./100m
Attenuation @ 2150MHz 33.3dB max./100m
|
